| Sensing range | 25 to 80 mm 0.985 to 3.150 in (Conv. Point: 50 mm 1.969 in)
with white non-glossy paper (100 x 100 mm 3.937 x 3.937 in) |
|---|
| Hysteresis | 10% or less of operation distance |
|---|
Repeatability
(perpendicular to sensing axis) | 0.5 mm 0.019 in |
|---|
| Supply voltage | 24 V DC±10 % Ripple P-P 10 % or less |
|---|
| Current consumption | 30 mA or less |
|---|
| Output | NPN open-collector transistor
・Maximum sink current: 100 mA
・Applied voltage: 30 V DC or less (between output and 0 V)
・Residual voltage:
1.0 V or less (at 100 mA sink current)
0.4 V or less (at 16 mA sink current) |
|---|
| | Output operation | Light-ON |
|---|
| Response time | 8 ms or less |
|---|
| Sensitivity adjuster | Continuously variable adjuster |
|---|
| Protection | IP64 (IEC) |
|---|
| Ambient temperature | -5 to +45 ℃ +23 to +113 ℉,
Storage: -10 to +60 ℃ +14 to +140℉ |
|---|
| Emitting element | Infrared LED (modulated) |
|---|
| Material | Heat-resistant ABS |
|---|
| Cable | 0.2 mm2 3-core oil-resistant, heat-resistant, cold-resistant cable, 1.5 m 4.921 ft long |
|---|
| Weight | Net weight: 65 g approx. |
|---|
| Accessory | Adjusting screwdriver: 1 pc. |
|---|
