| Applicable sensor | Digital pressure sensor DP-100 series, DPC-100 series, DPC-L100 series,
Digital fiber sensor FX-100 series |
|---|
| Supply voltage (Note 1) | 12 V DC [AC adapter (accessory): Input 100 to 240 V AC 50 / 60 Hz] |
|---|
| Power consumption | On operating: 5 VA or less (at 100V AC)
Stand by: 1.5 VA or less (at 100V AC) |
|---|
Repeatability of connecting
and disconnecting (Note 2) | 5,000 times approx. |
|---|
| Ambient temperature | 0 to +40 ℃ +32 to +104 ℉ (No dew condensation allowed),
Storage: −10 to +60 ℃ +14 to +140 ℉ |
|---|
| Ambient humidity | 35 to 85 % RH, Storage: 35 to 85 % RH |
|---|
| Indicator | Power indicator: Green LED, ENTER indicator: Yellow LED |
|---|
| Material | Enclosure base: ABS, Top cover: ABS, Rubber foot: Natural rubber |
|---|
| Weight | Net weight: 190 g approx., Gross weight: 350 g approx. |
|---|
| Accessories | AC adapter: 1 pc.
Connector board for DP-100 series (4-pin): 1 pc. (2 pcs. are attached to the product.)
Connector board for DPC-100 series (6-pin): 3 pcs.
Connector board for FX-100 series: 1 pc. (1 pc. is attached to the product.)
Fuse: 1 pc. |
|---|
| Dimensions | W 140 × H 50.5 × D 90 mm W 5.512 × H 1.988 × D 3.543 in |
|---|
